Single Station Plastic Pipe Winder Machine | Automated Coiler for HDPE, PVC & Corrugated Pipes

Motor Power:
Availability:
Quantity:
Optimize your extrusion line with the Single Station Plastic Pipe Winder – an automated, high-speed coiler for HDPE, PVC, and corrugated pipes. Explore adjustable speeds up to 12m/min.
  • SPS

  • Chenxing

Product Description

Single Station WinderThe Single Station Plastic Pipe Winder Machine is a high-speed plastic winder engineered for seamless coiling of HDPE, LDPE, and PVC pipes (Ø32-110mm) in extrusion lines. Featuring automated winding with adjustable speeds (3-12m/min) and pneumatic controls, this industrial pipe coiler ensures precise, orderly winding for flexible pipes and corrugated tubing. Its compact design integrates with extruders, haul-off units, and calibration systems, while the air-operated discharging and accumulator function synchronize coiling speed with production lines, minimizing downtime. Ideal for PVC pipe manufacturing and solid-wall tubing, this automated plastic winder combines efficiency, durability, and user-friendly operation for industrial applications.


Technical Parameters

applicability:Φ32-Φ63-Φ110 mm
coil speed:3-12 m/min(can be adjusted)
coil diameter:Φ400-Φ700-Φ1200 mm
motor power:100N/M   250N/M   700N/M

Remarks:all information above is only for reference; please gather the exact data by contacting us.

Detailed Photos

FAQ

FAQs
  • What pipe materials and diameters does this machine support?
    Created with Sketch.
    形状 Created with Sketch.
    The Single Station Winder handles HDPE, LDPE, PVC, and corrugated pipes with diameters ranging from Ø32mm to Ø110mm, making it versatile for diverse extrusion needs.
  • How does the pneumatic control system enhance coiling efficiency?
    Created with Sketch.
    形状 Created with Sketch.
    The air-operated discharging and wheel adjustments ensure rapid coil changes and precise alignment, reducing manual intervention in industrial pipe coiling.
  • Can this machine synchronize with existing extrusion lines?
    Created with Sketch.
    形状 Created with Sketch.
    Yes. It integrates seamlessly with extruders, haul-off units, and calibration systems, ensuring automated coiling aligned with production speeds.
  • Do you offer customization for specific pipe dimensions or automation levels?
    Created with Sketch.
    形状 Created with Sketch.
    Custom configurations, including tailored coil diameters (up to Ø1200mm) and advanced PLC controls, are available for specialized extrusion requirements.
