Oil Type Industrial Mould Temperature Controller | PID-Controlled Heating System for Plastic Automotive Production

Availability:
Quantity:
Industrial-grade mould temperature controller with Japan RKC PID (±1°C stability), stainless steel cooling, and oil circulation heating. Ideal for automotive, packaging, and electronics industries.
  • MKR

  • Chenxing

Product Description

The Oil Type Plastic Industry Mould Temperature Controller is a high-precision mold temperature controller designed for demanding plastic injection molding applications. Equipped with Japan RKC PID control technology, it achieves temperature stability within ±1°C, ensuring gloss enhancement and quality consistency for molded products. Featuring a stainless steel cooling system and oil circulation heating, this energy-efficient temperature controller supports both water and oil media, while its compact industrial mold heater design saves space and simplifies installation. With automatic fault alarms, power cutoff protection, and a corrosion-resistant tank, it guarantees long-term reliability in industries like automotive, packaging, and electronics.

Technical Parameters

ModelMKR-1MKR-2MKR-3MKR-4MKR-5MKR-6
Range of control temp (ºC)45-160ºC (45-250ºC)45-160ºC (45-250ºC)45-160ºC (45-250ºC)45-160ºC (45-250ºC)45-160ºC (45-250ºC)45-160ºC (45-250ºC)
Temperature controlJapan RKC PID ControlJapan RKC PID ControlJapan RKC PID ControlJapan RKC PID ControlJapan RKC PID ControlJapan RKC PID Control
Power source (V)380V 50Hz380V 50Hz380V 50Hz380V 50Hz380V 50Hz380V 50Hz
Heating mediaOilOilOilOilOilOil
Cooling methodIndirect coolingIndirect coolingIndirect coolingIndirect coolingIndirect coolingIndirect cooling
Motor power (kw)0.750.750.750.750.750.75
Heating power (kw)369122032
Dier volume (m3/h)303060100140200
Pump pressure222.5334
Cooling water pipe1/1/1/1/1/1/
Recycle water pipe1/3/3/1111/
Dimension(mm)600×310×640700×310×640770×310×700800×350×8001100×600×130001300×600×1300
Weight(kg)45607090110120

Remarks: all information above is only for reference; please gather the exact data by contacting us.

Detailed Photos


FAQ

FAQs
  • What industries commonly use this temperature controller?
    Created with Sketch.
    形状 Created with Sketch.
    It is widely used in automotive parts manufacturing, plastic packaging, electronics molding, and consumer goods production.
  • What is the temperature control accuracy?
    Created with Sketch.
    形状 Created with Sketch.
    The PID technology ensures a precision of ±1°C, critical for maintaining product consistency and surface gloss.
  • Is the stainless steel tank corrosion-resistant?
    Created with Sketch.
    形状 Created with Sketch.
    Absolutely. The tank is designed for long-term use, preventing rust and pipe blockages even with continuous oil circulation.
  • How does the automatic alarm system work?
    Created with Sketch.
    形状 Created with Sketch.
    The system triggers visual/audio alerts and cuts power immediately if faults (e.g., overheating, pump failure) are detected.
