Double-Cavity PVC/UPVC Pipe Extrusion Line | High-Speed Twin-Tube Production System

Availability:
Quantity:
Double your output with our Two-Cavity PVC/UPVC Pipe Extrusion Line – featuring independent tube control, stainless steel calibration, and automated haul-off for large-diameter pipes up to Ø50mm.
  • PVC

  • Chenxing

Product Description


The PVC/UPVC Pipe Extrusion Line (Two-Cavity) is a high-efficiency industrial system designed for simultaneous production of dual PVC/UPVC pipes (up to Ø50mm) with precision and flexibility. Featuring a double-cavity mould and stainless steel spray calibration technology, this line eliminates cross-interference during adjustments, ensuring independent control over each pipe. Equipped with automated twin-tube haul-off (0-15m/min speed) and dual-control cutting systems, it maximizes productivity for applications in agricultural, construction, and industrial piping. With 2000N haul-off force and energy-efficient extruder output (120-240 kg/h), this two-cavity extrusion line is ideal for large-scale UPVC pipe manufacturing, offering seamless customization for specialty pipe designs.




Product Parameters

Main technical datas of PVC double pipe extruder machine:


Pipe range

16-40mm

16-63mm

Extruder

SJZ51/105

SJZ65/132

Extruder power

18.5kw

37kw

Extrusion capacity

120kg/h

250kg/h

Max. Production speed

2 x 8m/min

2 x 10m/min


System configuration of PVC double pipe extruder machine:


1

SJSZ51/105(or SJSZ65/132)Conical Twin Srew Plastic Extruder

2

Mould

3

Vacuum Calibration Tank

4

Two caterpillars Hauling Machine

5

Pipe Cutting Machine

6

Stacker


Related auxiliary machines for optional:


1

High speed mixer unit

2

Crusher

3

Pulverizer

4

Pipe belling machine

5

Water chiller

6

Printing machine



Detailed Photos

FAQ

FAQs
  • What is a Two Cavity PVC Pipe Extrusion Line?
    Created with Sketch.
    形状 Created with Sketch.
    A Two Cavity PVC Pipe Extrusion Line is a manufacturing system designed to produce two PVC pipes simultaneously, effectively doubling production capacity without the need for additional equipment. ​
  • What are the advantages of using a Two Cavity PVC Pipe Extrusion Line?
    Created with Sketch.
    形状 Created with Sketch.
    The primary advantages include increased production efficiency, reduced labor costs, and optimized use of floor space, making it ideal for manufacturers aiming to boost output while maintaining quality.
  • What is the typical production capacity of this extrusion line?
    Created with Sketch.
    形状 Created with Sketch.
    Production capacities vary based on the specific model and pipe sizes. For example, a Two Cavity PVC Pipe Extrusion Line can produce pipes ranging from 16mm to 63mm in diameter, with outputs up to 250 kg/h. ​
  • What are the key components of the Two Cavity PVC Pipe Extrusion Line?
    Created with Sketch.
    形状 Created with Sketch.
    Key components include a conical twin-screw extruder, dual-cavity mold, vacuum calibration tank, haul-off unit, cutting machine, and stacking system. These components work together to ensure efficient and high-quality pipe production. ​
