Single-Wall Corrugated Pipe Extrusion Line | High-Speed Production for Automotive, Electrical & Industrial Tubing

Model:
Availability:
Quantity:
Produce durable, UV-resistant PP/PE/PVC corrugated pipes with our automated extrusion line. Ideal for automotive wiring, cable protection, and industrial drainage. Explore high-speed, customizable solutions.
  • SJ

  • Chenxing

Product Description


 Corrugated Pipe Production Line

The Single-Wall Corrugated Pipe Extrusion Line is a high-speed, versatile production system designed for manufacturing PP, PE, and PVC corrugated pipes with diameters ranging from 4mm to 6.7mm. Engineered for automotive wiring, electrical conduits, and industrial drainage, this line features anti-corrosion, UV-resistant pipes capable of withstanding temperatures from -40°C to 110°C. Equipped with a precision single-screw extruder, optimized forming molds, and automated winding systems, it ensures smooth interior/exterior surfaces and uniform. Ideal for applications in appliance drain pipes, cable protection, and automotive ventilation, this energy-efficient line supports rapid mold changes and delivers high-strength, abrasion-resistant tubing for demanding environments.

Product Parameters

Pipe diameter range(mm)

4.5-9

9-32

32-50

Main machine model

SJ-30

SJ-45

SJ-65

Main machine l/d

30:1

28:1

30:1

Production capacity kg/h

10

40

80

Main motor capacity kw

4

11

18.5

Moiding machine capacity kw

1.1

1.5

1.5

Pair of modules

42

38

38

Cooling mode

Water cooling and fan cooling

Production (m/min)

6-10

8-12

8-15

Metering mode

inductiing mode

Coiling machine mode

Motor-drivenManually-operated

Remarks: all information above is only for reference; please gather the exact data by contacting us.

Detailed Photos

FAQ

FAQs
  • What materials can this extrusion line process?
    Created with Sketch.
    形状 Created with Sketch.
    The line supports PP, PE, and PVC materials, producing pipes resistant to oil, acid, alkali, and UV exposure.
  • What industries benefit most from this corrugated pipe line?
    Created with Sketch.
    形状 Created with Sketch.
    It is ideal for automotive wiring, electrical cable protection, appliance drainage, and industrial ventilation systems.
  • What is the maximum production speed?
    Created with Sketch.
    形状 Created with Sketch.
    The high-speed corrugated forming machine achieves rapid output, with winding speeds tailored to pipe diameter and application.
  • How energy-efficient is this system?
    Created with Sketch.
    形状 Created with Sketch.
    Advanced motor controls and automated cooling systems reduce energy consumption by 20-30% compared to traditional lines.
